Applied Models | Supports creating volumes across different units |
|
|---|---|---|
| Notes |
| |
Storage | Drive Bays | 12 |
| Compatible Drive Type* (See all supported drives) |
| |
| Maximum Internal Raw Capacity | 192 TB (16 TB drive x 12) (Capacity may vary by RAID types) | |
| Hot Swappable Drive | ||
| RAID Management through Synology DSM | ||
External Ports | Expansion Port | 1 |
Appearance | Size (Height x Width x Depth) | 88 mm x 430.5 mm x 664 mm 88 mm x 430.5 mm x 692 mm (for RP model) |
| Size (Height x Width x Depth) (with server ears) | 88 mm x 482 mm x 696 mm 88 mm x 482 mm x 724 mm (for RP model) | |
| Weight | 12.7 kg 13.4 kg (for RP model) | |
| Rack Installation Support* | 4-post 19″ rack (Synology Rail Kit – RKS1317) | |
| Notes | The rail kit is sold separately | |
Power | Power Recovery | Synchronized with the Synology RackStation |
| Power Supply Unit / Adapter | 500 W | |
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption* | 68.60 W (Access) 27.45 W (HDD Hibernation) 71.3 W (Access) (for RP model) 31.2 W (HDD Hibernation) (for RP model) | |
| British Thermal Unit | 234.23 BTU/hr (Access) 93.73 BTU/hr (HDD Hibernation) 243.52 BTU/hr (Access) (for RP model) 106.53 BTU/hr (HDD Hibernation) (for RP model) | |
| Redundant Power Supply (for RP model) | ||
| Notes | Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). | |
Temperature | Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Others | System Fan | 80 mm x 80 mm x 3 pcs |
| Easy Replacement System Fan | ||
| Noise Level* | 54.6 dB(A) 54.2 dB(A) (for RP model) | |
| Notes | Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8% | |
Certification |
| |
Warranty | 5 Years | |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
Environment & Packaging | ||
Environment | RoHS Compliant | |
Packaging Content |
| |
Optional Accessories | Synology Rail Kit Sliding – RKS1317 | |
